KINGONE
ATV 3000 SR
电动绞盘 · ATV 3000 SR
适用场景与工作类型
便携工具
动力户外
牵引绞盘
便携工具
动力户外
牵引绞盘
- 额定拉力
- 3,000 lbs（1,361 kgf）
- Heavy duty series wound motor delivers superior torque output and faster line speed.
- 3 stage planetary gear box delivers the most reliable and durable performance of winch under the worst condition.
- Automatic, double cone brake.
- Rotating ring gear clutch has the free spooling positioned actually for the rapid payout of wire rope with ease.
- Installation ,operation and maintenance with ease.
← 技术规格由51winch提供 · 购买请前往 Mywinch选购平台
规格表
Specification
| Line pull: | 1363kgs/3,000lbs |
|---|---|
| Motor: | 12V/1.0HP 24V/0.8HP |
| Gear Train: | Three stage |
| Gear Ratio: | 166:1 |
| Freespooling Clutch: | Rotating ring gear |
| Sythetic Rope Size: | Φ6/31"×50'(Φ4.9mm×15.2m) |
| Drum Size: | Φ2.2"×3.4"(Φ55mm×87.5mm) |
Packaging
| Item | Value |
|---|---|
| Winch Weight | 9.67kgs/21.3lbs |
| Gross Weight | 11.64kgs/25.6lbs |
| Box Dimension | 390×209×235 mm(15.4"×8.2"×9.3") |
性能数据
Line Pull
| 1 | 3,000lbs/1,363kgs |
|---|---|
| 2 | 2,590lbs/1,170kgs |
| 3 | 2,270lbs/1,030kgs |
| 4 | 2,030lbs/920kgs |
| 5 | 1,830lbs/830kgs |
Line Speed and AMP Draw (1st layer of rope on the drum)
| Load | Line Speed | AMP Draw(12V) | AMP Draw(24V) |
|---|---|---|---|
| No Load | 24FPM/7.3MPM | 25 | 13 |
| 500lbs/230kgs | 19FPM/6.0MPM | 50 | 27 |
| 1,000lbs/450kgs | 15FPM/4.6MPM | 85 | 45 |
| 1,500lbs/680kgs | 13.5FPM/4.2MPM | 105 | 53 |
| 2,000lbs/900kgs | 11.4FPM/3.5MPM | 118 | 60 |
| 2,500lbs/1,140kgs | 10.2FPM/3.1MPM | 160 | 90 |
| 3,000lbs/1,363kgs | 8.2FPM/2.5MPM | 188 | 110 |
外形尺寸
