ATV 3000C SR
KINGONE

ATV 3000C SR

电动绞盘 · ATV 3000C SR

适用场景与工作类型
便携工具 便携工具 动力户外 动力户外 牵引绞盘 牵引绞盘
额定拉力
3,000 lbs（1,361 kgf）
🛒 去Mywinch购买 咨询技术支持

← 技术规格由51winch提供 · 购买请前往 Mywinch选购平台

规格表

Specification

Line pull:1363kgs/3,000lbs
Motor:12V/1.0HP 24V/0.8HP
Gear Train:Three stage
Gear Ratio:166:1
Freespooling Clutch:Rotating ring gear
Sythetic Rope Size:Φ6/31"×50'(Φ4.9mm×15.2m)
Drum Size:Φ2.2"×3.4"(Φ55mm×87.5mm)

Packaging

ItemValue
Winch Weight9.67kgs/21.3lbs
Gross Weight11.64kgs/25.6lbs
Box Dimension390×209×235 mm(15.4"×8.2"×9.3")

性能数据

Line Pull

13,000lbs/1,363kgs
22,590lbs/1,170kgs
32,270lbs/1,030kgs
42,030lbs/920kgs
51,830lbs/830kgs

Line Speed and AMP Draw (1st layer of rope on the drum)

LoadLine SpeedAMP Draw(12V)AMP Draw(24V)
No Load24FPM/7.3MPM2513
500lbs/230kgs19FPM/6.0MPM5027
1,000lbs/450kgs15FPM/4.6MPM8545
1,500lbs/680kgs13.5FPM/4.2MPM10553
2,000lbs/900kgs11.4FPM/3.5MPM11860
2,500lbs/1,140kgs10.2FPM/3.1MPM16090
3,000lbs/1,363kgs8.2FPM/2.5MPM188110

外形尺寸

ATV 3000C SR 机身尺寸图1
