KINGONE
ATV 4000 SR
电动绞盘 · ATV 4000 SR
适用场景与工作类型
便携工具
动力户外
牵引绞盘
便携工具
动力户外
牵引绞盘
- 额定拉力
- 4,000 lbs（1,814 kgf）
← 技术规格由51winch提供 · 购买请前往 Mywinch选购平台
规格表
Specification
| Line pull: | 1,814kgs/4,000lbs |
|---|---|
| Motor: | 12V/1.6HP 24V/1.0HP |
| Gear Train: | Three stage |
| Gear Ratio: | 187:1 |
| Freespooling Clutch: | Rotating ring gear |
| Synthetic Rope Size: | Φ6/31"×50'(Φ4.9mm×15.2m) |
| Drum Size: | Φ2.3"×5.2"(Φ59mm×131.5mm) |
Packaging
| Item | Value |
|---|---|
| Winch Weight | 9.66kgs/21.3lbs |
| Gross Weight | 11.65kgs/25.6lbs |
| Box Dimension | 430×225×235 mm(16.9"×8.9"×9.3") |
性能数据
Line Pull
| 1 | 4,000lbs/1,814kgs |
|---|---|
| 2 | 3,735lbs/1,694kgs |
| 3 | 3,188lbs/1,446kgs |
| 4 | 2,780lbs/1,261kgs |
Line Speed and AMP Draw (1st layer of rope on the drum)
| Load | Line Speed | AMP Draw(12V) | AMP Draw(24V) |
|---|---|---|---|
| No Load | 19FPM/5.8MPM | 25 | 13 |
| 500lbs/230kgs | 12.8FPM/3.9MPM | 45 | 26 |
| 1,000lbs/450kgs | 11.2FPM/3.4MPM | 80 | 45 |
| 1,500lbs/680kgs | 10.2FPM/3.1MPM | 120 | 60 |
| 2,000lbs/900kgs | 9.5FPM/2.9MPM | 160 | 89 |
| 2,500lbs/1,140kgs | 9.0FPM/2.7MPM | 210 | 120 |
| 3,000lbs/1,363kgs | 7.9FPM/2.4MPM | 235 | 130 |
| 3,500lbs/1,588kgs | 7.2FPM/2.2MPM | 250 | 135 |
| 4,000lbs/1,814kgs | 6.6FPM/2.0MPM | 278 | 145 |
外形尺寸
