KINGONE
KDS 10.0C
电动绞盘 · KDS 10.0C
适用场景与工作类型
牵引绞盘
牵引绞盘
- 额定拉力
- 10,000 lbs（4,536 kgf）
- Heavy duty series wound motor delivers superior torque output and faster line speed.
- 3 stage planetary gearbox delivers the most reliable and durable performance of winch under the worst condition.
- Braking by flanges transmission.
- Rotating ring gear clutch have the freespooling positioned actually for the rapid pay out of wire rope with ease.
- Installation ,operation and maintenance with ease.
- It's total length is 520mm(20.5").
← 技术规格由51winch提供 · 购买请前往 Mywinch选购平台
规格表
Specification
| Line pull: | 4,536kgs/10,000lbs |
|---|---|
| Motor: | 12V/5.0HP 24V/3.2HP |
| Gear Train: | Three stage |
| Gear Ratio: | 173:1 |
| Brake: | Flanges brake |
| Freespooling Clutch: | Rotating ring gear |
| Wire Rope Size: | Φ11/32"×100'(Φ8.7mm×30m) |
| Wire Rope Type: | Aircraft A7× 19 |
| Drum Size: | Φ2.5"×9"(Φ63.5mm×229mm) |
Packaging
| Item | Value |
|---|---|
| Winch Weight | 40kgs/88lbs |
| Gross Weight | 44.8kgs/98.6lbs |
| Box Dimension | 580×198×450 mm(22.8"×7.8"×17.7") |
性能数据
Line Pull, Line Speed & AMP Draw (1st layer of rope on the drum)
| Layer of Wire | Max Line Pull(6:1) |
|---|---|
| 1 | 10,000Lbs/4,536Kgs |
| 2 | 8,196Lbs/3,718Kgs |
| 3 | 6,888Lbs/3,124Kgs |
| 4 | 5,990Lbs/2,717Kgs |
外形尺寸
