KINGONE
KDS 9.0
电动绞盘 · KDS 9.0
适用场景与工作类型
牵引绞盘
牵引绞盘
- 额定拉力
- 9,000 lbs（4,082 kgf）
- Heavy duty series wound motor delivers superior torque output and faster line speed.
- 3 stage planetary gearbox delivers the most reliable and durable performance of winch under the worst condition.
- Braking by flanges transmission.
- Rotating ring gear clutch have the freespooling positioned actually for the rapid pay out of wire rope with ease.
- Installation ,operation and maintenance with ease.
- It's total length is 520mm(20.5").
← 技术规格由51winch提供 · 购买请前往 Mywinch选购平台
规格表
Specification
| Line pull: | 4,083kgs/9,000lbs |
|---|---|
| Motor: | 12V/4.8HP |
| Gear Train: | Three stage |
| Gear Ratio: | 254:1 |
| Brake: | Flanges brake |
| Freespooling Clutch: | Rotating ring gear |
| Wire Rope Size: | Φ5/16"×100'(Φ8.0mm×27m) |
| Wire Rope Type: | Aircraft A7× 19 |
| Drum Size: | Φ2.5"×9"(Φ63.5mm×229mm) |
Packaging
| Item | Value |
|---|---|
| Winch Weight | 39kgs/85.8lbs |
| Gross Weight | 44.5kgs/97.9lbs |
| Box Dimension | 560×198×405 mm(22"×7.8"×16") |
性能数据
Line Pull, Line Speed & AMP Draw (1st layer of rope on the drum)
| Layer of Wire | Max Line Pull(6:1) |
|---|---|
| 1 | 9,000Lbs/4,083Kgs |
| 2 | 7,370Lbs/3,342Kgs |
| 3 | 6,230Lbs/2,825Kgs |
| 4 | 5,390Lbs/2,447Kgs |
外形尺寸
