KINGONE
TDS 12.0
电动绞盘 · STANDARD TDS 12.0
适用场景与工作类型
牵引绞盘
牵引绞盘
- 额定拉力
- 12,000 lbs（5,443 kgf）
- Heavy duty series wound motor delivers superior torque output and faster line speed.
- 3 stage planetary gearbox delivers the most reliable and durable performance of winch under the worst condition.
- Automatic,double cone brake.
- Rotating ring gear clutch have the free spooling positioned actually for the rapid pay out of wire rope with ease.
- Installation ,operation and maintenance with ease.
← 技术规格由51winch提供 · 购买请前往 Mywinch选购平台
规格表
Specification
| Specification | TDS 12.0 |
|---|---|
| Line Pull | 5,442kgs/12,000lbs |
| Motor | 12V/6.0HP 24V/3.6HP |
| Gear Train | Three stage |
| Gear Ratio | 254:1 |
| Freespooling Clutch | Rotating ring gear |
| Drum Size | Φ2.5"×9"(Φ63.5mm×229mm) |
| Wire Rope Size | Φ3/8"×90'(Φ9.5mm×27.4m) |
| Wire Rope Type | Aircraft A7×19 |
| Synthetic Rope Size | Φ11/28"×90'(Φ10mm×27.4m) |
Packaging
| Package | TDS 12.0 |
|---|---|
| Winch Weight | 43kgs/94.6lbs |
| Gross Weight | 45kgs/99lbs |
| Box Dimension | 647×198×410 mm(25.5"×7.8"×16.1") |
性能数据
Line Pull
| Layer of Rope | Max Line Pull |
|---|---|
| 1 | 12,000lbs/5,442kgs |
| 2 | 9,789lbs/4,445kgs |
| 4 | 8,273lbs/3,760kgs |
| 3 | 7,199lbs/3,255kgs |
Line Speed and AMP Draw (1st layer of rope on the drum)
| Load | Line Speed | AMP Draw(12V) | AMP Draw(24V) |
|---|---|---|---|
| No Load | 31FPM/9.5MPM | 60 | 60 |
| 2,000lbs/907kgs | 13.9FPM/4.2MPM | 116 | 87 |
| 4,000lbs/1,814kgs | 11.5FPM/3.5MPM | 150 | 121 |
| 6,000lbs/2,722kgs | 9.9FPM/3.0MPM | 198 | 167 |
| 8,000lbs/3,650kgs | 8.6FPM/2.6MPM | 240 | 190 |
| 9,500lbs/4,309kgs | 7.9FPM/2.4MPM | 268 | 229 |
| 11,000lbs/5,000kgs | 7.2FPM/2.2MPM | 300 | 244 |
| 12,000lbs/5,442kgs | 5.9FPM/1.8MPM | 320 | 252 |
外形尺寸
