电动绞盘 · STANDARD TDS 13.0
适用场景与工作类型
牵引绞盘
牵引绞盘
- 额定拉力
- 13,000 lbs（5,897 kgf）
- Heavy duty series wound motor delivers superior torque output and faster line speed.
- 3 stage planetary gearbox delivers the most reliable and durable performance of winch under the worst condition.
- Automatic,double cone brake.
- Rotating ring gear clutch have the free spooling positioned actually for the rapid pay out of wire rope with ease.
- Installation ,operation and maintenance with ease.
← 技术规格由51winch提供 · 购买请前往 Mywinch选购平台
规格表
Specification
| Specification | TDS 13.0 |
|---|---|
| Line Pull | 5,897kgs/13,000lbs |
| Motor | 12V/6.0HP 24V/3.6HP |
| Gear Train | Three stage |
| Gear Ratio | 261:1 |
| Freespooling Clutch | Rotating ring gear |
| Wire Rope Size | Φ3/8"×90'(Φ9.5mm×27.4m) |
| Wire Rope Type | Aircraft A7×19 |
| Drum Size | Φ3.5"×8.1"(Φ89mm×206mm) |
| Synthetic Rope Size | Φ10mm×25M |
Packaging
| Package | TDS 13.0 |
|---|---|
| Winch Weight | 62.5kgs/137.5lbs |
| Gross Weight | 70.1kgs/154.2lbs |
| Box Dimension | 710×255×450 mm(28"×10"×17.7") |
性能数据
Line Pull
| Layer of Wire Rope | Max Line Pull |
|---|---|
| 1 | 13,000lbs/5,897kgs |
| 2 | 10,475lbs/4,752kgs |
| 3 | 9,017lbs/4,091kgs |
| 4 | 7,915lbs/3,590kgs |
| 5 | 7,100lbs/3,220kgs |
Line Speed and AMP Draw (1st layer of rope on the drum)
| Load | Line Speed | AMP Draw(12V) | AMP Draw(24V) |
|---|---|---|---|
| No Load | 24FPM/7.3MPM | 55 | 49 |
| 6,000lbs/2,722kgs | 6.6FPM/2.0MPM | 210 | 172 |
| 10,000lbs/4,536kgs | 4.0FPM/1.2MPM | 290 | 260 |
| 13,000lbs/5,897kgs | 2.6FPM/0.8MPM | 350 | 310 |
外形尺寸
