KINGONE
TDS 16.5C
电动绞盘 · STANDARD TDS 16.5C
适用场景与工作类型
牵引绞盘
牵引绞盘
- 额定拉力
- 16,500 lbs（7,484 kgf）
- Heavy duty series wound motor delivers superior torque output and faster line speed.
- 3 stage planetary gearbox delivers the most reliable and durable performance of winch under the worst condition.
- Automatic,double cone brake.
- Rotating ring gear clutch have the free spooling positioned actually for the rapid pay out of wire rope with ease.
- Installation ,operation and maintenance with ease.
← 技术规格由51winch提供 · 购买请前往 Mywinch选购平台
规格表
Specification
| Specification | Text |
|---|---|
| Line Pull | 7,485kgs/16,500lbs |
| Motor | 12V/6.0HP 24V/3.6HP |
| Gear Train | Three stage |
| Gear Ratio | 315:1 |
| Freespooling Clutch | Rotating ring gear |
| Drum Size | Φ3.5"×8.1"(Φ89mm×206mm) |
| Wire Rope Type | Aircraft A7×19 |
| Synthetic Rope Size | Φ7/16"×83'(Φ11mm×25m) |
| Wire Rope Size | Φ7/16"×90'(Φ11mm×27.4m) |
Packaging
| Title | TDS 16.5C |
|---|---|
| Winch Weight | 65.5kgs/144.1lbs |
| Gross Weight | 72.9kgs/160.4lbs |
| Box Dimension | 710×270×420 mm(28"×10.6"×16.5") |
性能数据
Line Pull
| Title | Line Pull |
|---|---|
| 1 | 16,500lbs/7,485kgs |
| 2 | 12,292lbs/5,576kgs |
| 3 | 10,413lbs/4,724kgs |
| 4 | 9,033lbs/4,097kgs |
Line Speed and AMP Draw (1st layer of rope on the drum)
| Title | Line Speed | AMP Draw(12V) | AMP Draw(24V) |
|---|---|---|---|
| No Load | 18FPM/5.5MPM | 65 | 49 |
| 6,000lbs/2,722kgs | 6.3FPM/1.9MPM | 190 | 95 |
| 10,000lbs/4,536kgs | 4.0FPM/1.2MPM | 255 | 195 |
| 13,000lbs/5,897kgs | 3.4FPM/1.0MPM | 330 | 220 |
| 14,500lbs/6,350kgs | 2.9FPM/0.9MPM | 380 | 260 |
| 16,500lbs/7,484kgs | 2.1FPM/0.6MPM | 400 | 290 |
外形尺寸
