KINGONE
TDS 6.5
电动绞盘 · STANDARD TDS 6.5
适用场景与工作类型
牵引绞盘
牵引绞盘
- 额定拉力
- 6,500 lbs（2,948 kgf）
- Heavy duty series wound motor delivers superior torque output and faster line speed.
- 3 stage planetary gearbox delivers the most reliable and durable performance of winch under the worst condition.
- Automatic,double cone brake.
- Rotating ring gear clutch have the free spooling positioned actually for the rapid pay out of wire rope with ease.
- Installation ,operation and maintenance with ease.
← 技术规格由51winch提供 · 购买请前往 Mywinch选购平台
规格表
Specification
| Title | TDS 6.5 |
|---|---|
| Synthetic Rope Size | Φ2/7"×80'(Φ7.2mm×30m) |
| Line Pull | 2,955kgs/6,500lbs |
| Motor | 12V/4.0HP |
| Gear Train | Three stage |
| Gear Ratio | 173:1 |
| Freespooling Clutch | Rotating ring gear |
| Drum Size | Φ2.5"×9"(Φ63.5mm*229mm) |
| Wire Rope Size | Φ5/16"×80'(Φ8.0mm×24.3m) |
| Wire Rope Type | Aircraft A7×19 |
Packaging
| Package | TDS 6.5 |
|---|---|
| Winch Weight | 40kgs/88lbs |
| Gross Weight | 42kgs/92.4lbs |
| Box Dimension | 647×198×410 mm(25.5"×7.8"×16.1") |
性能数据
Line Pull
| Layer of Rope | Max Line Pull |
|---|---|
| 1 | 6,500lbs/2,955kgs |
| 2 | 5,000lbs/2,300kgs |
| 3 | 4,300lbs/2,000kgs |
| 4 | 3,800lbs/1,700kgs |
Line Speed and AMP Draw (1st layer of rope on the drum)
| Load | Line Speed | AMP Draw(12V) |
|---|---|---|
| No Load | 59FPM/16MPM | 70 |
| 2,000lbs/907kgs | 16.4FPM/5MPM | 150 |
| 4,000lbs/1,814kgs | 13FPM/4MPM | 240 |
| 6,500lbs/2,955kgs | 8.2FPM/2.5MPM | 380 |
| 8,500lbs/3,860kgs |
外形尺寸
