KHD 10
液压绞盘 · KHD 10
适用场景与工作类型
消防救援
牵引绞盘
消防救援
牵引绞盘
- 额定拉力
- 10,000 lbs（4,536 kgf）
- Smooth running over the entire speed range.
- Highly efficient, constant operating torque motor.
- Rotating ring gear frees pooling clutch is a pull and turn design for rapid wire rope payout.
- Freespooling. Power in/out. Mechanical lock. Stainless steel tie bars . Reversible mounting.
- Variable speed hydraulic winch.
← 技术规格由51winch提供 · 购买请前往 Mywinch选购平台
规格表
Specification
| Line pull: | 756kgs/1,667lbs(high) 4,535kgs/10,000lbs(low) |
|---|---|
| Operation Pressure: | 175bar/2,537psi |
| Max Oil Flow: | 15.9g/min(60l/min) |
| Gear Ratio: | Free 1:1(HIGH) 6:1(LOW) |
| Wire Rope Size: | Φ3/8"×90'(Φ9.5mm×27.4m) |
| Drum Size: | Φ2.5"×8.4"(Φ63.5mm×215mm) |
| Gear Train: | Planetary |
Packaging
| Item | Value |
|---|---|
| Winch Weight | 43kgs/94.8lbs |
| Gross Weight | 48kgs/105.8lbs |
| Box Dimension | 570×245×305 mm(22.4"×9.6"×12") |
性能数据
LINE PULL AND LINE SPEED(1st layer of Synthetic Rope on the drum)(please use under when the max line pull is 10,000lbs,pressure is 175 bar and flow is 30l/min.)
| Layer of Wire | RopeMax Line Pull(1:1) | Line Speed(1:1) | Max Line Pull(6:1) | Line Speed(6:1) |
|---|---|---|---|---|
| 1 | 1,667Lbs/756Kgs | 134.5FPM/41MPM | 10,000Lbs/4,535Kgs | 21.3FPM/6.5MPM |
| 2 | 1,389Lbs/630Kgs | 161FPM/49MPM | 8,320Lbs/3,770Kgs | 26.2FPM/8MPM |
| 3 | 1,212Lbs/550Kgs | 183.7FPM/56MPM | 7,120Lbs/3,330Kgs | 30.5FPM/9.3MPM |
| 4 | 1,058Lbs/480Kgs | 209FPM/64MPM | 6,200Lbs/2,812Kgs | 36.1FPM/11MPM |
| 5 | 922Lbs/450Kgs | 223FPM/68MPM | 5,500Lbs/2,490Kgs | 37FPM/11.3MPM |
外形尺寸
