KINGONE
KHD 8
液压绞盘 · KHD 8
适用场景与工作类型
消防救援
牵引绞盘
消防救援
牵引绞盘
- 额定拉力
- 8,000 lbs（3,629 kgf）
- Smooth running over the entire speed range.
- Highly efficient, constant operating torque motor.
- Rotating ring gear frees pooling clutch is a pull and turn design for rapid wire rope payout.
- Freespooling. Power in/out. Mechanical lock. Stainless steel tie bars . Reversible mounting.
- Variable speed hydraulic winch.
← 技术规格由51winch提供 · 购买请前往 Mywinch选购平台
规格表
Specification
| Line pull: | 605kgs/1,333lbs(high) 3,629kgs/8,000lbs(low) |
|---|---|
| Operation Pressure: | 175bar/2,537psi |
| Max Oil Flow: | 15.9g/min(60l/min) |
| Gear Ratio: | Free 1:1(HIGH) 6:1(LOW) |
| Wire Rope Size: | Φ3/8"×90'(Φ9.5mm×27.4m) |
| Drum Size: | Φ2.5"×8.4"(Φ63.5mm×215mm) |
| Gear Train: | Planetary |
Packaging
| Item | Value |
|---|---|
| Winch Weight | 42kgs/92.6lbs |
| Gross Weight | 47kgs/103.6lbs |
| Box Dimension | 570×245×305 mm(22.4"×9.6"×12") |
性能数据
LINE PULL AND LINE SPEED(1st layer of Synthetic Rope on the drum)(please use under when the max line pull is 8,000lbs,pressure is 175 bar and flow is 30l/min.)
| Layer of Wire | RopeMax Line Pull(1:1) | Line Speed(1:1) | Max Line Pull(6:1) | Line Speed(6:1) |
|---|---|---|---|---|
| 1 | 1,333Lbs/650Kgs | 160FPM/49MPM | 8,000Lbs/3,629Kgs | 26.6FPM/8.1MPM |
| 2 | 1,120Lbs/500Kgs | 190FPM/58MPM | 6,700Lbs/3,030Kgs | 31.8FPM/9.7MPM |
| 3 | 992Lbs/450Kgs | 213FPM/65MPM | 5,900Lbs/2,670Kgs | 36FPM/11MPM |
| 4 | 860Lbs/390Kgs | 249FPM/76MPM | 5,100Lbs/2,310Kgs | 41FPM/12.5MPM |
| 5 | 780Lbs/354Kgs | 279FPM/85MPM | 4,600Lbs/2,080Kgs | 46.5FPM/14.2MPM |
外形尺寸
