RUNVA
HWX 10000YD
液压绞盘 · HWX 10000YD
RUNVA HWX 10000YD 液压绞盘参数与性能数据。
适用场景与工作类型
牵引绞盘
牵引绞盘
- 额定拉力
- 10,000 lbs（4,536 kgf）
← 技术规格由51winch提供 · 购买请前往 Mywinch选购平台
规格表
| Rated line pull | 10000 lbs (4536 kgs) |
|---|---|
| Motor:permanent magnet | 50ml/r |
| Oil flow | 15~40L/min |
| Pressure | 12.5Mpa |
| Brake | Automatic screw cone |
| Geartrain | 2-stage planetary alloy gear |
| Gear reduction ratio | 28:1 |
| Waterproof | IP54 |
| Cable(Dia×L) | Ø3/8″×85’(Ø9.2mm×26m) |
| Drum size(Dia×L) | Ø2.6″×8.5″(Ø66mm×217mm) |
| Mounting bolt pattern | 19.7″×21.7″×5.0″ (500mm×550mm×126.3mm)8-M12 |
| Net weight | 96.3lbs/43.7kgs |
性能数据
| PERFORMANCE SPECS (first layer) | ||||
|---|---|---|---|---|
| Line Pull | Pressure | Flow | Line Speed | Pull by layer: |
| Lbs.(kgs) | Mpa(Psi) | G/min. (L/min.) | Ft/min. (M/min.) | layer/Lbs.(kgs) |
| 0 | 2.0(290.1) | 4.0(15) | 7.2(2.2) | 1/10000 (4536) |
| 4000 (1814) | 3.9(565.6) | 6.6(25) | 12.5(3.8) | 2/7969(3615) |
| 6000 (2722) | 7.5(1087.7) | 9.2(35) | 17.7(5.4) | 3/6624(3005) |
| 8000 (3629) | 10.5(1522.8) | 10.6(40) | 20.0(6.1) | 4/5667(2571) |
| 10000 (4536) | 12.5(1812.9) |
外形尺寸
